ADI JFET輸入運算放大器
發布時間：2021-09-15 17:02:52 瀏覽：6748
ADI的JFET輸入運算放大器或FastFET?高速(>50MHz)輸入運算放大器提供高輸入阻抗和超低輸入偏置電流，適用于高速技術應用。ADI的FET輸入運算放大器大部分具備+5V至±12V或以上的寬電源電壓范圍，而且提供軌到軌輸出，適用寬動態范圍。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.liaoyuan999.com/brand/25.html
或聯系ADI的銷售工程師： 0755-83642657 QQ: 2295048674
產品型號 | # of Amps | GBP (typ) | Slew Rate (typ) | Ibias (max) | VNoise Density (typ) | Iq/Amp (typ) | Vs span (min) | Vs span (max) |
|
| Hz | V/us | A | V/rtHz | A | V | V |
ADA4625-2 | 2 | 18M | 48 | 75p | 3.3n | 4m | 5 | 36 |
ADA4625-1 | 1 | 18M | 48 | 75p | 3.3n | 4m | 5 | 36 |
ADA4622-4 | 4 | 8M | 23 | 10p | 12.5n | 665μ | 5 | 30 |
ADA4622-1 | 1 | 8M | 23 | 10p | 12.5n | 715μ | 5 | 30 |
ADA4530-1 | 1 | 2M | 1.4 | 20f | 14n | 900μ | 4.5 | 16 |
ADA4622-2 | 2 | 8M | 23 | 10p | 12.5n | 665μ | 5 | 30 |
ADA4350 | 1 | 175M | 100 | 1p | 5n | 8.5m | 3.3 | 12 |
ADA4610-1 | 1 | 16.3M | 25 | 25p | 7.3n | 1.6m | 10 | 36 |
ADA4610-4 | 4 | 16.3M | 25 | 25p | 7.3n | 1.6m | 10 | 36 |
AD8244 | 4 |
| 800m | 3p | 13n | 180μ | 3 | 36 |
ADA4001-2 | 2 | 16.7M | 25 | 30p | 7.7n | 2m | 9 | 36 |
ADA4610-2 | 2 | 16.3M | 25 | 25p | 7.3n | 1.6m | 10 | 36 |
AD823A | 2 | 10M | 35 | 25p | 13n | 5.1m | 3 | 36 |
ADA4637-1 | 1 | 79.9M | 170 | 5p | 4.8n | 7m | 9 | 30 |
ADA4062-4 | 4 | 1.4M | 3.3 | 50p | 36n | 165μ | 8 | 36 |
ADA4627-1 | 1 | 19M | 56 | 5p | 4.8n | 7m | 9 | 36 |
ADA4062-2 | 2 | 1.4M | 3.3 | 50p | 36n | 165μ | 8 | 36 |
ADA4817-1 | 1 | 410M | 870 | 20p | 4n | 19m | 5 | 10 |
ADA4817-2 | 2 | 410M | 870 | 20p | 4n | 19m | 5 | 10 |
ADA4000-1 | 1 | 5M | 20 | 40p | 16n | 1.65m | 8 | 36 |
ADA4000-2 | 2 | 5M | 20 | 40p | 16n | 1.65m | 8 | 36 |
ADA4000-4 | 4 | 5M | 20 | 40p | 16n | 1.65m | 8 | 36 |
ADTL082 | 2 | 5M | 20 | 100p | 16n | 1.2m | 8 | 36 |
ADTL084 | 4 | 5M | 20 | 100p | 16n | 1.2m | 8 | 36 |
AD8682 | 2 | 3.5M | 9 | 20p | 36n | 210μ | 9 | 36 |
AD8684 | 4 | 3.5M | 9 | 20p | 36n | 210μ | 9 | 36 |
AD8642 | 2 | 3.5M | 3 | 1p | 27.5n | 290μ | 5 | 26 |
AD8643 | 4 | 3.5M | 3 | 1p | 27.5n | 290μ | 5 | 26 |
AD8641 | 1 | 3.5M | 3 | 1p | 27.5n | 290μ | 5 | 26 |
AD8513 | 4 | 8M | 20 | 80p | 7.6n | 2.5m | 9 | 30 |
AD8625 | 4 | 5M | 5 | 1p | 16n | 850μ | 5 | 26 |
AD8626 | 2 | 5M | 5 | 1p | 16n | 850μ | 5 | 26 |
AD8627 | 1 | 5M | 5 | 1p | 16n | 850μ | 5 | 26 |
AD8067 | 1 | 200M | 640 | 5p | 6.6n | 7m | 5 | 24 |
AD8033 | 1 | 45M | 80 | 12p | 11n | 3.3m | 5 | 24 |
AD8066 | 2 | 145M | 180 | 7p | 7n | 7.4m | 5 | 24 |
AD8510 | 1 | 8M | 20 | 80p | 7.6n | 2.5m | 9 | 30 |
AD8034 | 2 | 45M | 80 | 12p | 11n | 3.3m | 5 | 24 |
AD8065 | 1 | 145M | 180 | 7p | 7n | 7.4m | 5 | 24 |
AD8620 | 2 | 25M | 60 | 10p | 6n | 3.5m | 10 | 26 |
AD8512 | 2 | 8M | 20 | 80p | 7.6n | 2.5m | 9 | 30 |
AD8610 | 1 | 25M | 60 | 10p | 6n | 3.5m | 10 | 26 |
LT1792 | 1 | 5.6M | 3.4 | 800p | 4.2n | 4.2m | 10 | 40 |
LT1793 | 1 | 4.2M | 3.4 | 10p | 6n | 4.2m | 10 | 40 |
AD825 | 1 | 26M | 140 | 40p | 12n | 6.5m | 10 | 36 |
LT1462 | 2 | 175k | 130m | 2p | 76n | 28μ | 10 | 40 |
LT1463 | 4 | 175k | 130m | 2p | 76n | 28μ | 10 | 40 |
LT1465 | 4 | 1M | 900m | 2p | 24n | 145μ | 10 | 40 |
LT1464 | 2 | 1M | 900m | 2p | 24n | 145μ | 10 | 40 |
AD823 | 2 | 10M | 25 | 30p | 16n | 5.2m | 3 | 36 |
AD824 | 4 | 2M | 2 | 35p | 16n | 560μ | 2.7 | 30 |
LT1169 | 2 | 5.3M | 4.2 | 20p | 6n | 5.3m | 9 | 40 |
LT1457 | 2 | 1M | 4 | 500p | 13n | 1.8m | 9 | 40 |
LT1113 | 2 | 5.6M | 3.9 | 450p | 4.5n | 5.3m | 9 | 40 |
AD822 | 2 | 1.8M | 3 | 12p | 13n | 900μ | 5 | 30 |
AD820 | 1 | 1.8M | 3 | 10p | 13n | 900μ | 5 | 30 |
AD795 | 1 | 1.6M | 1 | 2p | 9n | 1.5m | 8 | 36 |
OP282 | 2 | 4M | 9 | 100p | 36n | 210μ | 9 | 36 |
OP482 | 4 | 4M | 9 | 100p | 36n | 210μ | 9 | 36 |
AD745 | 1 | 20M | 12.5 | 250p | 2.9n | 10m | 9.6 | 36 |
AD743 | 1 | 4.5M | 2.8 | 400p | 2.9n | 10m | 9.6 | 36 |
LT1122 | 1 | 14M | 80 | 75p | 14n | 7.5m | 20 | 40 |
AD746 | 2 | 13M | 75 | 250p | 16n | 4m | 9 | 36 |
AD843 | 1 | 34M | 250 | 1n | 19n | 12m | 9 | 36 |
OP249 | 2 | 4.7M | 22 | 75p | 16n | 3.5m | 9 | 36 |
AD713 | 4 | 4M | 20 | 150p | 16n | 3m | 9 | 36 |
AD845 | 1 | 16M | 100 | 1n | 12n | 10m | 9.5 | 36 |
AD744 | 1 | 13M | 75 | 100p | 16n | 3.5m | 9 | 36 |
AD549 | 1 | 1M | 3 | 60f | 35n | 700μ | 10 | 36 |
OP42 | 1 | 10M | 52 | 250p | 12n | 5.1m | 16 | 40 |
RH1056A | 1 | 6.5M | 10 | 50p | 28n | 6.5m | 8 | 40 |
AD648 | 2 | 1M | 1.8 | 10p | 30n | 170μ | 9 | 36 |
AD711 | 1 | 4M | 20 | 50p | 16n | 2.8m | 9 | 36 |
AD712 | 2 | 4M | 20 | 75p | 16n | 2.8m | 9 | 36 |
LT1057 | 2 | 5M | 14 | 50p | 13n | 1.6m | 8 | 40 |
LT1057MH/883 | 2 | 5M | 14 | 50p | 13n | 1.6m | 8 | 40 |
LT1058 | 4 | 5M | 14 | 50p | 13n | 1.6m | 8 | 40 |
LT1022 | 1 | 8.5M | 26 | 50p | 14n | 5.2m | 20 | 40 |
LT1022AMH/883 | 1 | 8.5M | 26 | 50p | 14n | 5.2m | 20 | 40 |
LT1055 | 1 | 4.5M | 12 | 50p | 15n | 2.8m | 8 | 40 |
LT1056 | 1 | 5.5M | 14 | 50p | 15n | 5m | 8 | 40 |
