ADI高速模數轉換器(> 10MSPS)
發布時間：2021-05-14 16:59:25 瀏覽：1812
ADI的高速模數轉換器（ADC）提供了整個市場上最好的性能指標和最高的采樣速率。產品包含高中頻ADC（10MSPs至125MSPS）、低中頻ADC（125MSPs至1GSPS）、集成化接收機和寬帶ADC（>1GSPS）。高速ADC系列產品為所有的高速轉換應用領域提供解決方案。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.liaoyuan999.com/brand/25.html
或聯系ADI的銷售工程師： 0755- 83642657 QQ： 2295048674
*部分型號需申請出口許可
*詳情咨詢更多型號請聯系我們的工程師！
產品型號 | Channels | Resolution | Sample Rate (max) | ADC SNR in dBFS (typ) | INL in LSB (typ) | Vin Range (typ) | Power (typ) |
|
| bits | SPS | dBFS | LSBs | V p-p | W |
AD9081 | 4 | 16 | 4G | 59 | 7 | 1.5 | 8.5 |
AD9083 | 16 | 14 | 2G | 66 |
| 0.5 | 1.45 |
ADA4355 | 1 | 14 | 125M |
| 1.5 |
| 540m |
AD9082 | 2 | 12 | 6G | 59 | 7 | 1.5 | 8.8 |
AD9094 | 4 | 8 | 1G | 49.2 |
| 1.44 | 1.6 |
AD9213 | 1 | 12 | 10.25G | 57.5 | 2.4 | 1.4 | 5.1 |
AD9697 | 1 | 14 | 1.3G | 65.6 | 1 | 1.59 | 1.01 |
LTM2173-14 | 4 | 14 | 80M | 73 | 1 | 2 | 385m |
AD9689-2000 | 2 | 14 | 2G | 62.7 | 2 | 1.59 | 2.5 |
AD9689-2600 | 2 | 14 | 2.6G | 61.3 | 6 | 1.59 | 3.1 |
AD9695-1300 | 2 | 14 | 1.3G | 65.6 | 1 | 1.59 | 1.6 |
AD9695-625 | 2 | 14 | 625M | 67.2 | 2 | 1.59 | 980m |
AD9246S | 1 | 14 | 125M | 71.9 | 1.5 | 2 | 458m |
AD6688 | 2 | 14 | 3G | 67.7 | 6 | 1.7 | 3.3 |
AD9208 | 2 | 14 | 3G | 60.2 | 6 | 1.7 | 3.3 |
AD6684 | 4 | 14 | 500M | 68.4 | 1 | 1.8 | 1.68 |
AD9694 | 4 | 14 | 500M | 67.1 | 1 | 1.8 | 1.66 |
AD9691 | 2 | 14 | 1250M | 63.4 | 2.6 | 1.58 | 3.8 |
AD6679 | 2 | 14 | 500M | 68.9 | 2.5 | 2.06 | 2.2 |
AD9684 | 2 | 14 | 500M | 69.2 | 2.5 | 2.06 | 2.2 |
AD9655 | 2 | 16 | 125M | 79.6 | 4 | 2.8 | 313m |
AD9690-1000 | 1 | 14 | 1G | 67.2 | 2.5 | 1.7 | 2 |
AD9690-500 | 1 | 14 | 500M | 69.2 | 2.5 | 2.06 | 1.5 |
AD6676 | 1 | 16 | 3.2G |
|
| 1.92 | 1.2 |
LTC2122 | 2 | 14 | 170M | 70 | 1.2 | 1.5 | 751m |
LTC2123 | 2 | 14 | 250M | 70 | 0.85 | 1.5 | 864m |
AD6674-1000 | 2 | 14 | 1G | 67.2 | 2.5 | 1.7 | 3.3 |
AD6674-500 | 2 | 14 | 500M | 67.3 | 2.5 | 2.06 | 2.2 |
AD6674-750 | 2 | 14 | 750M | 69.2 | 2.5 | 1.7 | 2.8 |
AD8285 | 4 | 12 | 72M | 68 |
| 0.25 | 185m |
AD9234-1000 | 2 | 12 | 1G | 64.2 | 35 | 1.34 | 3 |
AD9234-500 | 2 | 12 | 500M | 65.9 |
| 1.63 | 2.15 |
HMCAD5831 | 1 | 3 | 26G | 19.2 | 0.3 | 0.256 | 4.2 |
LTC2107 | 1 | 16 | 210M | 79.8 | 1.6 | 2.5 | 1.28 |
AD9625-2000 | 1 | 12 | 2G | 59.5 | 0.9 | 1.1 | 3.48 |
AD9625-2500 | 1 | 12 | 2.5G | 58.3 | 1 | 1 | 3.9 |
AD9625-2600 | 1 | 12 | 2.6G | 58.1 | 1 | 1 | 4 |
AD9652 | 2 | 16 | 310M | 75.4 | 4.5 | 2.5 | 2160m |
AD9680-1000 | 2 | 14 | 1G | 67.2 | 2.5 | 1.7 | 3.3 |
AD9680-1250 | 2 | 14 | 1.25G | 63.6 | 3 | 1.58 | 3.7 |
AD9680-500 | 2 | 14 | 500M | 69.2 | 2.5 | 2.06 | 2.2 |
AD9680-820 | 2 | 14 | 820M | 67.2 | 2.5 | 1.7 | 2.9 |
AD9656 | 4 | 16 | 125M | 80.1 | 4.5 | 2.8 | 788m |
AD9249 | 16 | 14 | 65M | 75.4 | 0.9 | 2 | 924m |
AD9671 | 8 | 14 | 125M | 75 |
| 1 | 1.2 |
AD9675 | 8 | 14 | 125M | 75 |
| 1 | 1.2 |
AD9681 | 8 | 14 | 125M | 74.8 | 1.2 | 2 | 879m |
LTM9013 | 2 | 14 | 310M | 59 | 4.5 | 1.3 | 2.6 |
