ADI數模轉換器的快速精密數模轉換器和標準高速數模轉換器
發布時間：2020-08-26 16:09:03 瀏覽：4108
ADI快速精密數模轉換器用于直流和交流性能測試和測量，以及HIL應用，ADI的快速精密數模轉換器(DAC)可以產生12.5MSPS的高速波形，并提供干凈的信號頻譜和4倍的過采樣性能。
ADI數模轉換器產品系列為dac的高速和精密應用提供了解決方案。擁有完整的數據手冊和評估板，以及廣泛的時鐘和時序、射頻、電源管理和運算放大器產品組合支持，adi的dac可以幫助減少上市時間和降低系統設計成本。高達GSPS、8至16位分辨率和小封裝的高速范圍僅是我們行業領先的數模轉換器的一部分好處。
深圳市立維創展科技是ADI的經銷商。ADI芯片產品供應：放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖和光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處置器和DSP、射頻和圖形處置器、開關和分路器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
快速精密數模轉換器
產品型號 | # of Channels | Resolution | Update Rate | SFDR (typ) | Iout FS (max) | 數據輸入接口 | Package |
|
| bits | SPS | dB | A |
|
|
LTC1666 | 1 | 12 | 50M | 78 | 10m | Parallel | 28-Lead SSOP |
LTC1667 | 1 | 14 | 50M | 78 | 10m | Parallel | 28-Lead SSOP |
LTC1668 | 1 | 16 | 50M | 78 | 10m | Parallel | 28-Lead SSOP |
標準高速數模轉換器
產品型號 | # of Channels | Resolution | Update Rate | Nois
e Spectral Density (typ) | SFDR (typ) | Power (typ) |
|
| bits | SPS | dBm/Hz | dB | W |
AD9166 | 1 | 16 | 12G | 154 | 46 | 4.88 |
AD9174 | 2 | 16 | 12.6G | 165 | 72 | 2.55 |
AD9175 | 2 | 16 | 12.6G | 165 | 72 | 2.55 |
AD9176 | 2 | 16 | 12.6G | 165 | 72 | 2.55 |
AD9171 | 2 | 16 | 6G | 165 | 72 | 2.55 |
AD9173 | 2 | 16 | 12.6G | 165 | 72 | 2.55 |
AD9172 | 2 | 16 | 12.6G | 165 | 72 | 2.55 |
AD9161 | 1 | 11 | 12G | 155 | 65 | 2.35 |
AD9162 | 1 | 16 | 12G | 164 | 70 | 2.35 |
AD9163 | 1 | 16 | 12G | 164 | 70 | 2.65 |
AD9164 | 1 | 16 | 12G | 164 | 70 | 2.35 |
LTC2000A-11 | 1 | 11 | 2.7G | 156 | 82 | 2.408 |
LTC2000A-14 | 1 | 14 | 2.7G | 163 | 82 | 2.408 |
LTC2000A-16 | 1 | 16 | 2.7G | 164 | 82 | 2.408 |
AD9152 | 2 | 16 | 2.25G | 163 | 72 | 1.223 |
AD9154 | 4 | 16 | 2.4G | 163 | 73 | 2.11 |
AD9135 | 2 | 11 | 2.8G | 157 | 76 | 1.42 |
AD9136 | 2 | 16 | 2.8G | 163 | 76 | 1.42 |
LTC2000-11 | 1 | 11 | 2.5G | 156 | 82 | 2.2 |
LTC2000-14 | 1 | 14 | 2.5G | 164 | 82 | 2.2 |
LTC2000-16 | 1 | 16 | 2.5G | 166 | 82 | 2.2 |
AD9144 | 4 | 16 | 2.8G | 163 | 76 | 1.59 |
AD9142A | 2 | 16 | 1.6G | 166 | 85 | 1.5 |
AD9139 | 1 | 16 | 1.6G | 164.5 | 85 | 700m |
AD9119 | 1 | 11 | 5.7G | 157 | 76 | 1.1 |
AD9129 | 1 | 14 | 5.7G | 166 | 76 | 1.1 |
AD9142 | 2 | 16 | 1.6G | 166 | 85 | 1.7 |
AD9737A | 1 | 11 | 2.5G |
| 70 | 960m |
AD9121 | 2 | 14 | 1.23G | 163 | 80 | 1.5 |
AD9146 | 2 | 16 | 1.2G | 164 | 67 | 864m |
AD9739A | 1 | 14 | 2.5G |
| 70 | 960m |
AD9125 | 2 | 16 | 1G | 164 | 72 | 913m |
AD9148 | 4 | 16 | 1G | 162.5 | 65 | 1.49 |
AD9122 | 2 | 16 | 1.23G | 163 | 72 | 1.5 |
AD9739 | 1 | 14 | 2.5G |
| 69.5 | 1.16 |
AD768S | 1 | 16 | 30M |
| 86 |
|
AD9114 | 2 | 8 | 125M | 132 | 76 | 232m |
AD9115 | 2 | 10 | 125M | 143 | 85 | 232m |
AD9116 | 2 | 12 | 125M | 153 | 85 | 232m |
AD9117 | 2 | 14 | 125M | 157 | 85 | 232m |
AD9714 | 2 | 8 | 125M | 129 | 75 | 35m |
AD9715 | 2 | 10 | 125M | 141 | 82 | 35m |
AD9716 | 2 | 12 | 125M | 149 | 83 | 35m |
AD9717 | 2 | 14 | 125M | 152 | 84 | 35m |
AD9789 | 4 | 14 | 2.4G |
| 70 | 1.6 |
AD9785 | 2 | 12 | 800M |
| 85 | 450m |
AD9787 | 2 | 14 | 800M |
| 82 | 1054m |
AD9788 | 2 | 16 | 800M |
| 90 | 1054m |
AD9780 | 2 | 12 | 500M |
| 79 | 440m |
AD9781 | 2 | 14 | 500M |
| 78 | 440m |
AD9783 | 2 | 16 | 500M |
| 80 | 440m |
AD9776A | 2 | 12 | 1.1G | 157.5 | 85 | 572m |
AD9778A | 2 | 14 | 1G |
| 85 | 980m |
AD9779A | 2 | 16 | 1G |
| 87 | 980m |
AD9743 | 2 | 10 | 250M | 144 | 80 | 300m |
AD9745 | 2 | 12 | 250M | 155 | 80 | 305m |
AD9746 | 2 | 14 | 250M | 160 | 80 | 310m |
AD9747 | 2 | 16 | 250M | 162 | 80 | 310m |
AD9704 | 1 | 8 | 175M | 136 | 60 | 57m |
AD9705 | 1 | 10 | 175M | 144 | 59 | 57m |
AD9706 | 1 | 12 | 175M | 152 | 59 | 57m |
AD9707 | 1 | 14 | 175M | 152 | 60 | 57m |
AD9726 | 1 | 16 | 400M |
| 78 | 652m |
AD9778 | 2 | 14 | 1G |
| 85 | 300m |
AD9779 | 2 | 16 | 1G |
| 87 | 980m |
AD9734 | 1 | 10 | 1.2G |
| 76 | 380m |
AD9735 | 1 | 12 | 1.2G |
| 76 | 380m |
AD9736 | 1 | 14 | 1.2G |
| 80 | 380m |
AD9786 | 1 | 16 | 500M |
| 93 | 685m |
AD9748 | 1 | 8 | 210M |
| 72 | 145m |
ADV7125 | 3 | 8 | 330M |
|
|
|
AD9740 | 1 | 10 | 210M |
| 90 | 145m |
AD9742 | 1 | 12 | 210M |
| 90 | 145m |
AD9744 | 1 | 14 | 210M | 155 | 90 | 145m |
AD9773 | 2 | 12 | 160M |
| 84.5 | 380m |
AD9775 | 2 | 14 | 160M |
| 84.5 | 380m |
AD9777 | 2 | 16 | 160M |
| 85 | 380m |
LTC1666 | 1 | 12 | 50M |
| 78 | 180m |
LTC1667 | 1 | 14 | 50M |
| 78 | 180m |
AD9751 | 1 | 10 | 300M |
| 80 | 155m |
AD9753 | 1 | 12 | 300M |
| 82 | 155m |
AD9755 | 1 | 14 | 300M |
| 84 | 155m |
AD9772A | 1 | 14 | 160M |
| 82 | 253m |
AD9709 | 2 | 8 | 125M |
| 63 | 450m |
LTC1668 | 1 | 16 | 50M |
| 78 | 180m |
AD9763 | 2 | 10 | 125M |
| 78 | 450m |
AD9765 | 2 | 12 | 125M |
| 81 | 450m |
AD9767 | 2 | 14 | 125M |
| 82 | 450m |
AD9750 | 1 | 10 | 125M |
| 82 | 190m |
AD9752 | 1 | 12 | 125M |
| 84 | 220m |
AD9754 | 1 | 14 | 125M |
| 86 | 220m |
AD9731S | 1 | 10 | 170M |
| 79 | 439m |
ADV7127 | 1 | 10 | 240M |
|
| 310m |
ADV7123 | 3 | 10 | 330M |
| 70 | 485m |
AD9761 | 2 | 10 | 40M |
| 68 | 200m |
AD9764 | 1 | 14 | 125M |
| 82 | 170m |
AD9708 | 1 | 8 | 125M |
| 67 | 140m |
AD9760 | 1 | 10 | 125M |
| 78 | 190m |
AD9760-50 | 1 | 10 | 50M |
|
| 175m |
AD9762 | 1 | 12 | 125M |
| 79 | 190m |
AD768 | 1 | 16 | 30M |
| 86 | 465m |
