產(chǎn)品詳情介紹
| 低通濾波器 | ||||||
| 型號 | Passband (dB) | 3 dB Cutoff (MHz) | Stop Band Frequency (MHz) | |||
| Max | >35dB | >23dB | >23dB | |||
| FLHS-33 | 2 | 33 | ||||
| AFLS-6 | 6 | -- | -- | -- | -- | |
| FLS-12 | 10.7 | 12 | 21 | 19 | 16 | |
| FLP-12 | 10.7 | 12 | 21 | 19 | 16 | |
| FLP-24 | 21 | 24 | 42 | 37 | 32 | |
| FLS-24 | 21 | 24 | 42 | 37 | 32 | |
| FLS-33 | 30 | 33 | 58 | 51 | 44 | |
| FLP-90 | 82.8 | 24 | 42 | 37 | 32 | |
| FLS-100 | 92 | 100 | 175 | 155 | 133 | |
| FLS-154 | 140 | 154 | 270 | 235 | 208 | |
| FLS-220LF | 220 | -- | -- | -- | -- | |
| FLS-220 | 220 | -- | -- | -- | -- | |
| FLP-220 | 220 | -- | -- | -- | -- | |
| FLP-570 | 520 | 570 | 995 | 880 | 765 | |
| FLS-570 | 520 | 570 | 995 | 880 | 765 | |
| FLP-850 | 780 | 850 | 1485 | 1315 | 1130 | |
| FLS-850 | 780 | 850 | 1485 | 1315 | 1130 | |
| FLS-965 | 875 | 965 | 1690 | 1595 | 1495 | |
| FLS-1100 | 1000 | 1100 | 1925 | 1815 | 1700 | |
| 旁通濾波器 | ||||||
| 型號 | Center | Insertion | Passband | 40 dB BW (MHz) | > 35 dB | 20 dB BW (MHz) |
| (MHz) | Loss (Max.) | (MHz) | ||||
| FIS-21.4 | 21.4 | 1.5 | 19.6 - 23.2 | 6.8 | -- | 14.9 - 27.8 |
| FIS-21.4LF | 21.4 | 1.5 | 19.6 - 23.2 | 6.8 | -- | 14.9 - 27.8 |
| FIS-30 | 30 | 1.5 | 27.5 - 32.5 | 9.3 | -- | 21 - 39 |
| FIS-50 | 50 | 1.5 | 45.8 - 54.3 | 15.8 | -- | 35 - 65 |
| FIS-60 | 60 | 1.5 | 54.9 - 65.1 | 19 | -- | 42 - 78 |
| FIS-70 | 70 | 1.5 | 64 - 75.9 | 20.3 | -- | 49 - 91 |
| TFIS-70 | 70 | 1.5 | 64 - 75.69 | 20.3 | -- | 49 - 91.69 |
| FNS-10.7 | 10.7 | 1.7 | 10.2 - 11.2 | -- | -- | -- |
| FNS-200 | 200 | 2.7 | 190 - 210 | -- | -- | -- |
| FNS-400 | 400 | 3 | 380.9 - 420 | -- | -- | -- |
| FNS-450 | 450 | 3 | 428.6 - 472.5 | -- | -- | -- |
| FNS-500 | 500 | 3 | 475.2 - 525 | -- | -- | -- |
| FBS-11 | 10.7 | 3.5 | - | 8.5 | -- | 9.63 - 11.8 |
| FBS-30 | 30 | 3.5 | - | 24 | -- | 27 - 33 |
| FBS-50 | 50 | 4 | - | 40 | -- | 45 - 56 |
| FBS-140 | 140 | 5 | - | 108 | -- | 120 - 160 |
| 高通濾波器 | ||||||
| 型號 | Passband (dB) | 3 dB Cutoff (MHz) | Stop Band Frequency (MHz) | |||
| Max | 3dB Cutoff | >35dB | >23dB | >20dB | ||
| FHS-10 | 50 | 10 | 5 | 6 | 7 | |
| FHS-127 | 630 | 127 | 65 | 80 | 95 | |
| FHS-182 | 850 | 182 | 90 | 110 | 135 | |
| FHS-20 | 100 | 20 | 10 | 13 | 15 | |
| FHS-270 | 1200 | 270 | 135 | 170 | 200 | |
| FHS-27 | 150 | 27 | 14 | 17 | 20 | |
| FHS-410 | 1400 | 410 | 205 | 255 | 305 | |
| FHS-45 | 250 | 45 | 23 | 29 | 34 | |
| FHS-545 | 1600 | 545 | 225 | 320 | 410 | |
| FHS-55 | 300 | 55 | 28 | 35 | 41 | |
| FHS-64 | 300 | 64 | 32 | 40 | 48 | |
| FHS-680 | 1900 | 680 | 340 | 425 | 510 | |
| FHS-795 | 2000 | 795 | 400 | 500 | 600 | |
