μModule電池充電器LINEAR
發布時間：2022-10-14 16:36:56 瀏覽：887
ADI的μModule?(微模塊)電池充電器是一個完整的系統級包(SiP)充電解決方案，集成了DC/DC控制器，功率晶體管，輸入和輸出電容，補償組件和電感在一個緊湊的桌面安裝LGA包。μModule?(微模塊)電池充電器可與鋰離子電池、鋰離子聚合物電池、LiFePO4電池和鉛酸電池等需要恒流恒壓(CC/CV)充電的電池化學方法配合使用，為面臨時間和空間限制的工程師提供高效、可靠的電源管理解決方案。
ADI公司的隔離μModule?轉換器是完整的系統化封裝(SiP)電源管理解決方案，LINEAR電源在緊湊型表貼BGA封裝內集成DC/D阿C控制器、功率晶體管、輸入和輸出電容、補償組件以及725 VDC隔離變壓器。LINEAR電源的1.5 W輸出隔離反激式μModule轉換器可有效滿足面對時間和空間限制難題的工程師需要，為全球客戶提供高效、可靠的電源管理解決方案。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://www.liaoyuan999.com/brand/19.html
產品型號 | Vin (min) | Vin (max) | Output Current (typ) | Battery Chemistry | Number of Cells | Float Voltage |
| V | V | A |
|
| V |
LTM8064 | 6 | 58 | 6 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | Up to 36V float voltage | Up to 36V |
LTM8054 | 5 | 36 | 5.4 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | Up to 36V float voltage | Up to 36V |
LTM8055 | 5 | 36 | 8.5 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | Up to 36V float voltage | Up to 36V |
LTM8056 | 5 | 58 | 4 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | Up to 48V float voltage | Up to 48V |
LTM8026 | 6 | 36 | 5 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | Up to 24V float voltage | Up to 24V |
LTM8052 | 6 | 36 | 5 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | Up to 24V float voltage | Up to 24V |
LTM8052A | 6 | 36 | 5 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | Up to 24V float voltage | Up to 24V |
LTM8061 | 4.95 | 32 | 2 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | 1, 2 | 4.1V, 4.2V, 8.2V, 8.4V |
LTM8062 | 4.95 | 32 | 2 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | 1-4 Li-Ion/Li-Poly, 1-5 LiFePO4, SLA up to 14.4V | Up to 14.4V |
LTM8062A | 4.95 | 32 | 2 | Lead Acid, LiFePO4, Li-Ion, Li-Polymer | 1-4 Li-Ion/Li-Poly, 1-5 LiFePO4, SLA up to 18.8V | Up to 18.8V |
