LINEAR降壓型穩壓器和 LDO
發布時間：2022-09-13 16:41:11 瀏覽：872
LINEAR降壓型穩壓器和LDO是完整的電源管理解決方案，先進性便攜式應用程序基于處理器的系統。LINEAR降壓型穩壓器和LDO包括四個同步降壓DC/DC轉換器，適用于核心、內存、I/O和片上系統(SoC)供電軌道和三個300mALDO控制器，適用于低噪音模擬電源。I2C串口適用于控制穩壓器使能、關斷定時、輸出電壓水平、動態電壓調整、工作模式和狀態報告。
ADI公司的隔離μModule?轉換器是完整的系統化封裝(SiP)電源管理解決方案，LINEAR電源在緊湊型表貼BGA封裝內集成DC/D阿C控制器、功率晶體管、輸入和輸出電容、補償組件以及725 VDC隔離變壓器。LINEAR電源的1.5 W輸出隔離反激式μModule轉換器可有效滿足面對時間和空間限制難題的工程師需要，為全球客戶提供高效、可靠的電源管理解決方案。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://www.liaoyuan999.com/brand/19.html
產品型號 | Number of Outputs | Vin (min) | Vin (max) | Buck Output Current (typ) | LDO Output Current (typ) |
|
| V | V | A | A |
ADP5320 | 9 | 1.8 | 5.5 | 150m | 50m, 50m, 50m, 50m, 50m, 50m |
LT3380 | 7 | 2.7 | 5.5 | 1.5, 1.5, 2.5, 2.5 | 300m, 300m, 300m |
LT3383 | 7 | 2.7 | 5.5 | 1.5, 1.5, 2.5, 2.5 | 300m, 300m, 300m |
ADP5138 | 5 | 3 | 5.5 | 1, 1, 1, 1 | 250m |
ADP5003 | 2 | 4.2 | 15 | 3 | 3 |
LT3668 | 3 | 4.3 | 40 | 400m | 200m, 200m |
LT3667 | 3 | 4.3 | 40 | 400m | 200m, 200m |
ADP5080 | 8 | 4 | 15 | 800m, 1.15, 1.5, 2, 3 | 300m, 400m |
ADP5134 | 4 | 2.5 | 5.5 | 1.2, 1.2 | 300m, 300m |
ADP5050 | 5 | 4.5 | 15 | 1.2, 1.2, 4, 4 | 200m |
ADP5052 | 5 | 4.5 | 15 | 1.2, 1.2, 4, 4 | 200m |
LTM8001 | 6 | 6 | 36 | 5 | 1.1, 1.1, 1.1, 1.1, 1.1 |
ADP5040 | 3 | 2.3 | 5.5 | 1.2 | 300m, 300m |
ADP5041 | 3 | 2.3 | 5.5 | 1.2 | 300m, 300m |
ADP1876 | 3 | 2.75 | 20 | 25, 25 | 150m |
ADP5023 | 3 | 2.3 | 5.5 | 800m, 800m | 300m |
ADP5024 | 3 | 2.3 | 5.5 | 1.2, 1.2 | 300m |
ADP5037 | 4 | 2.3 | 5.5 | 800m, 800m | 300m, 300m |
ADP5033 | 4 | 2.3 | 5.5 | 800m, 800m | 300m, 300m |
ADP5034 | 4 | 2.3 | 5.5 | 1.2, 1.2 | 300m, 300m |
LT3507A | 4 | 4 | 36 | 1.8, 1.8, 2.7 | 1 |
ADP5043 | 2 | 2.3 | 5.5 | 800m | 300m |
LT3645 | 2 | 3.6 | 36 | 500m | 200m |
ADP5042 | 3 | 2.3 | 5.5 | 800m | 300m, 300m |
LTC3104 | 2 | 2.5 | 15 | 300m | 10m |
ADP2140 | 2 | 2.3 | 5.5 |
|
|
LT3694 | 3 | 4 | 36 | 2.6 | 1 |
LT3570 | 2 | 2.1 | 36 | 1.5 | 1 |
LT3507 | 4 | 4 | 36 | 1.5, 1.5, 2.4 | 1 |
LTC3100 | 3 | 650m | 5 | 250m | 100m |
LT1939 | 2 | 3 | 25 | 2 | 1 |
LT3500 | 2 | 3 | 36 | 2 | 1 |
LTC3672B-2 | 3 | 2.9 | 5.5 | 500m | 150m, 150m |
LTC3672B-1 | 3 | 2.9 | 5.5 | 500m | 150m, 150m |
LTC3670 | 3 | 2.5 | 5.5 | 500m | 150m, 150m |
LTC3541-2 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3541-3 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3446 | 3 | 2.7 | 5.5 | 1 | 300m, 300m |
LTC3541 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3541-1 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3445 | 3 | 2.5 | 5.5 | 600m | 50m, 50m |
LT1941 | 3 | 3.3 | 25 | 2, 3 |
|
LTC3700 | 2 | 2.65 | 9.8 | 5 | 150m |
LTC1704 | 2 | 3.15 | 5.5 | 20 | 2 |
